Features

"Dimensions
86mm * 103mm * 20mm

Material
PC + armored glass

Weight
130g

Voltage
DC 12V (5V – 30V)

Current
<160mA 12V

Interface
Wiegand, RS232, RS485

Image Sensor
640 x 480 CMOS, 30fps

View Angle
Horizontal 63’, Vertical 51’

Scan Angle
Roll: 360’, Pitch: ± 60’, Skew: ± 50’

Support Code
On by default: EAN13, EAN8, UPC-A, UPC-E0, UPC-E1, Code 128, Code 39, Code 93, CodaBar, QR Code, PDF417
DataMatrix Off by default, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code 11, MSI Plessey, RSS-14, RSS-Limited, RSS-Expanded

Reading Distance
30 – 230mm (6-inch mobile phone, WeChat QR payment code)

Resolution
1D: ≥ 5mil / 2D: ≥ 10mil

Symbol Contrast
≥ 25%

Recognition Mode
Active / passive, with support for induction mode

Scan Code Feedback Beep
Beeping: the green light indicates scanning code

Support Card
ISO14443A / B, support ID card physical ID, NFC mobile phone card

Operating Temperature
-20°C ~ 60°C

Operating Humidity
5%RH~95%RH (Non-Condensing)

Storage Temperature
-40°C ~ 80°C

Ambient Lighting
0–80000Lux

Electrostatic Protection
Contact discharge ± 6KV and air discharge ± 12KV

IP Protection
Front IP54"

Features

"Dimensions
86mm * 103mm * 20mm

Material
PC + armored glass

Weight
130g

Voltage
DC 12V (5V – 30V)

Current
<160mA 12V

Interface
Wiegand, RS232, RS485

Image Sensor
640 x 480 CMOS, 30fps

View Angle
Horizontal 63’, Vertical 51’

Scan Angle
Roll: 360’, Pitch: ± 60’, Skew: ± 50’

Support Code
On by default: EAN13, EAN8, UPC-A, UPC-E0, UPC-E1, Code 128, Code 39, Code 93, CodaBar, QR Code, PDF417
DataMatrix Off by default, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code 11, MSI Plessey, RSS-14, RSS-Limited, RSS-Expanded

Reading Distance
30 – 230mm (6-inch mobile phone, WeChat QR payment code)

Resolution
1D: ≥ 5mil / 2D: ≥ 10mil

Symbol Contrast
≥ 25%

Recognition Mode
Active / passive, with support for induction mode

Scan Code Feedback Beep
Beeping: the green light indicates scanning code

Support Card
ISO14443A / B, support ID card physical ID, NFC mobile phone card

Operating Temperature
-20°C ~ 60°C

Operating Humidity
5%RH~95%RH (Non-Condensing)

Storage Temperature
-40°C ~ 80°C

Ambient Lighting
0–80000Lux

Electrostatic Protection
Contact discharge ± 6KV and air discharge ± 12KV

IP Protection
Front IP54"

PDI provides physical devices for tangible progress.

Tradition means credibility. As opposed to software that can be installed on your smartphone and similar gadgets, our OEM hardware delivers purpose-built reliability, durability, and performance you can count on, integrating seamlessly into mission-critical systems where precision and longevity matter most.

Engineered for high-demand environments

Our devices are built to operate under continuous use, withstanding the rigors of real-world conditions across industries.

Unmatched accuracy and speed

From scanning to card reading, our hardware delivers fast, precise results that software alone can’t replicate.

Plug-and-perform integration

Designed for seamless integration with existing systems – no guesswork, no excessive configuration.

Secure by design

Physical hardware offers a level of security that software-based tools can’t match, especially in regulated industries like voting, transportation, and gaming.

Trusted by global institutions

Our products are at work in systems used by governments, transit authorities, and lottery commissions worldwide.

Long product lifecycle

Built to last, our equipment ensures years of dependable service with minimal (when non-existent) maintenance.
