MMD-1901/1902

MMD1901/1902 integrates the magnetic card reader function with data encryption. Upon reception of the magnetic head signals, the card data is recovered, encrypted, and transferred to the external device via universal asynchronous receiver and transmitter (UART) or serial peripheral interface (SPI). It supports up to 3 track card reading at the same time. Signal processing techniques are employed to recover F2F encoded data reliably from head signals with severe fluctuation of signal amplitude, widely varying bit interval, and jittery bit position. The recovered data is encrypted with the 128 bit AES.
get a free quote
Features

"Wide Range of Card Swipe Speeds: from 5 to 150 cm/s
Signal Conditioning Adapted to Head Signal
Flexible External Interface: UART or SPI
ISO/IEC 7811 and Binary Data Format Support
Encrypt all Track Data
Power Down Mode for Low Power Consumption
Full Three Tracks Support
Secure Data Transfer with 128 bit AES Encryption:
CBC Mode
DUKPT key management (Derived Unique Key Per Transaction)
Digital Signal Processing for Superior Data Recovery Performance
Development Kits Available"
Specifications

"Card Standard
ISO 7810/7811 and AAMVA

Card Speed
10 ~ 120 cm/sec (4-50 inch/sec)

Head Life Time
300,000 passes minimum

Operating Temperature
-40°C ~ +70°C

Storage Temperature
-40°C ~ +70°C

Power Input
3.0 – 3.6 VDC

Interface
SPI (Option: UART)

Message Format
ASCII"
Features

"Wide Range of Card Swipe Speeds: from 5 to 150 cm/s
Signal Conditioning Adapted to Head Signal
Flexible External Interface: UART or SPI
ISO/IEC 7811 and Binary Data Format Support
Encrypt all Track Data
Power Down Mode for Low Power Consumption
Full Three Tracks Support
Secure Data Transfer with 128 bit AES Encryption:
CBC Mode
DUKPT key management (Derived Unique Key Per Transaction)
Digital Signal Processing for Superior Data Recovery Performance
Development Kits Available"
Specifications

"Card Standard
ISO 7810/7811 and AAMVA

Card Speed
10 ~ 120 cm/sec (4-50 inch/sec)

Head Life Time
300,000 passes minimum

Operating Temperature
-40°C ~ +70°C

Storage Temperature
-40°C ~ +70°C

Power Input
3.0 – 3.6 VDC

Interface
SPI (Option: UART)

Message Format
ASCII"
